DCH614B
DEWALT® FLEXVOLT 60V MAX* Brushless Cordless 1-3/4-in. (45mm) SDS MAX Combination Rotary Hammer (Tool Only)
Reviews
Explore More Options
Current Option
Product details
Complete horizontal serial drilling, dry coring, chipping, and bushing applications with the 60V MAX* 1-3/4 in. SDS MAX Combination Hammer. Powered by a brushless motor and durable German engineered mechanism, this midweight hammer delivers 10.5 Joules of impact energy for fast drilling in hard concrete. Featuring constant-speed electronics that allow the tool to maintain speed under load and the patented E-CLUTCH system that detects the motion of the tool and shuts it down in bind-up situations, this drill offers THE POWER OF CORDED. FREEDOM OF CORDLESS.
- 10.5 Joules of impact energy for fast drilling and chipping, even in the hardest concrete.
- E-CLUTCH system protects the user in bind-up situations by stopping the rotation of the bit.
- Equipped with integrated WIRELESS TOOL CONTROL, which allows the user to link the tool to the DCV585 60V MAX* dust extractor for remote extractor activation.
- The SHOCKS active vibration control system reduces vibration felt by the user at the handles, compared to rotary hammers without this feature.
- 7-position, variable-speed control for precision hole placement, chipping, and drilling with Atomic Undercut bits.
- Brushless motor and durable German engineered mechanisms.
- Constant-speed electronics allow the tool to maintain speed under load.
- Tag Ready so users and companies can attach the DEWALT Tag and track its location virtually anywhere via the Tool Connect app.
- The midweight design makes it ideally suited for high-performance, horizontal serial drilling for #5 - #8 rebar, dry coring up to 4in., chipping in any upper to lower wall and bushing applications.
Product Type
Rotary Hammer Drill
Voltage
60 V
Cordless or Corded
Cordless
Power Source
Battery
Motor Type
Brushless
- (1) Atomic Undercut Bit Drilling
- (1) DCH614 60V MAX* Combination Rotary Hammer
- 3 Year Limited Warranty, 1 Year Free Service, 90 Days Satisfaction Guaranteed
We take extensive measures to ensure all our products are made to the very highest standards and meet all relevant industry regulations.
Customer Support* * Maximum initial battery voltage (measured without a workload) is 60 volts. Nominal voltage is 54.
Downloads and manuals
N687036_DCH614_NA.pdf
PDF
N687036_DCH614_NA.pdf
PDF
NA758264_DCH614_T3_NA.256330.pdf
PDF
Related products & accessories
Concrete power for commercial jobsites
Drill and chip through the hardest concrete with the largest offering of Cordless SDS MAX Combination Rotary Hammers. Featuring brushless motors and a German engineered mechanism, the 60V MAX* Combination Hammers power through the most demanding applications.
Metalworking
Grind with up to 30% more power†, when powered by a 20V/60V MAX* FLEXVOLT® battery.
Bare tool notice
This item does not include a battery or charger. Compatible batteries and accessories can be found within the FLEXVOLT 20V/60V MAX* system.
The battery innovation behind 20V/6…
FLEXVOLT® Battery System
Get the most out of your tool with a single battery system that offers exceptional power and runtime. Featuring patented technology that changes voltage when you change tools, FLEXVOLT 20V/60V MAX* batteries are compatible with 60V MAX* and 300+ 20V MAX* system tools.
