20V MAX* XR® Brushless Cordless 1 in. SDS PLUS L-Shape Rotary Hammer Kit
DCH273P2
20V MAX* XR® Brushless Cordless 1 in. SDS PLUS L-Shape Rotary Hammer Kit
- 2.1 Joules of impact energy for fast drilling in concrete
- Shocks active vibration control system reduces vibration felt by the user at the handles, compared to rotary hammers without this feature
- Lightweight design makes this tool ideal for rod hanging, seismic & safety attachments, cable tray & strut mounting, clamp mounting, and rail mounting
DCH273P2
20V MAX* XR® Brushless Cordless 1 in. SDS PLUS L-Shape Rotary Hammer Kit
- 2.1 Joules of impact energy for fast drilling in concrete
- Shocks active vibration control system reduces vibration felt by the user at the handles, compared to rotary hammers without this feature
- Lightweight design makes this tool ideal for rod hanging, seismic & safety attachments, cable tray & strut mounting, clamp mounting, and rail mounting
Product Details
Downloads
Complete tough applications with the 20V MAX* XR® 1 in. SDS PLUS L-Shape Rotary Hammer. The lightweight design makes this tool ideal for rod hanging, seismic and safety attachments, cable tray and strut mounting, clamp mounting, and rail mounting. Built with safety in mind, this hammer features the SHOCKS ACTIVE VIBRATION CONTROL® System to help limit the amount of vibration felt at the handles by the user. Use with DWH303DH Onboard Extractor for OSHA Table 1 Compliance. For user convenience, this product is packaged with (2) 20V MAX* batteries, a charger, and a durable kit box for portability on the jobsite.
- Tool Holder: SDS-Plus Battery chemistry: XR Li-Ion Voltage: 18 V Battery Capacity: 5.0 Ah Power Output: 400 Watt Impact energy (EPTA 05/2009): 2.1 J No Load Speed: 0-1100 rpm Blows per Minute: 0-4600 bpm Max. Drilling Capacity [Concrete]: 24 mm Max. Drilling Capacity [Wood]: 26 mm Max. Drilling Capacity [Metal]: 13 mm Weight: 3.1 kg Length: 301 mm Height: 202 mm Hand/Arm Vibration - Hammer drilling into concrete 1.5 m/s² Uncertainty K 2 (Vibration) greater than2.5 m/s² Hand/Arm Vibration - Screw driving without impact 1.5 m/s² Sound Pressure Uncertainty 97 dB(A)
|
Battery Capacity [Ah]
|
5
|
|
Battery Chemistry
|
XR Lithium Ion
|
|
Battery Type
|
Lithium Ion
|
|
Battery Voltage [V]
|
20
|
|
Chuck Size [in]
|
1
|
|
Chuck Type
|
SDS+
|
|
Color
|
Yellow
|
|
Impact Energy (J) EPTA Value
|
2.1 J
|
|
Is Brushless?
|
Yes
|
|
Max. Drilling Capacity (Steel) [mm]
|
13
|
|
Max. Drilling Capacity (Wood) [mm]
|
26
|
|
Number Of Pieces
|
1
|
|
Power Source
|
Cordless
|
|
Product Height [mm]
|
202
|
|
Product Length [mm]
|
301
|
|
Product Weight [g]
|
3100
|
|
Product Weight [Kg]
|
3.1
|
|
Product Weight [oz]
|
108.8
|
|
Product Width [mm]
|
85
|
|
Sound Pressure [dB(A)]
|
86
|
|
System
|
SHOCKS System
|
|
Uncertainty K1 (Vibration)
|
1.5 m/s2
|
|
Voltage [V]
|
18
|
|
Weight (w/o Battery) [g]
|
3110
|
- OSHA Table 1 Compliant when paired with DWH303DH On Board Extractor
- Brushless motor and durable German-engineered mechanism for efficient performance and runtime
- Rotating Dial to set tool to a specific applicaiton mode - Drill, Hammer Drill, or Chip
- (1) DCH273 Rotary hammer
- 3 Year Limited Warranty, 2 Years Free Service
We’re confident of the quality of our products, and we’ll repair, without charge, any defects due to faulty materials or workmanship within the specified warranty.
We take extensive measures to ensure all our products are made to the very highest standards and meet all relevant industry regulations.
Related Products
0 0
Popular Accessories
0 0
Batteries and Chargers
0 0
Up-sell Products
0 0
Disclaimer(s)
- * Maximum initial battery voltage (measured without a workload) is 20 volts. Nominal voltage is 18.
