DCD471B

DEWALT® FLEXVOLT 60V MAX* Brushless Cordless 7/16-in. (11mm) Quick-Change Stud and Joist Drill with E-Clutch System (Tool Only)

A DEWALT cordless power tool, specifically a FLEXVOLT right angle drill, featuring a black and yellow ergonomic design with dual handles and battery compartment visible.

Reviews

Explore More Options

Current Option

Product details

Take on your most challenging drilling applications with the 60V MAX* Cordless Quick Change Stud and Joist Drill. Built with safety in mind, this tool features the E-CLUTCH system that detects the motion of the tool and shuts it down in bind-up situations. Maintain productivity with a 7/16 in. hex quick-change chuck that delivers fast bit changes on demanding jobs. Battery & Charger Sold Separately

  • DEWALT anti-rotation E-CLUTCH system offers technology capable of detecting the motion of the tool and shuts it down in a bind-up situation. the red indicator led illuminates when the E-CLUTCH system is engaged
  • Fast bit change: 7/16 in. Hex quick-change chuck for easy bit changes
  • Control speed: 2-speed settings (0 rpm to 400 rpm/0 rpm to 1320 rpm) to match appropriate speed to the application
  • No need to feather trigger: Quick-shift speed selector allows the user to easily change speeds without having to feather the trigger
  • Reduced weight: Magnesium gear case reduces weight while maintaining durability
  • Cordless freedom: Power of corded with the freedom of cordless
  • Track the drill: TOOL CONNECT Tag Ready, install a DEWALT tool tag allows for tracking and locating of the drill using the DEWALT TOOL CONNECT app
  • Up to 4-5/8 in. self-feed bits into wood
  • Up to 6-1/4 in. hole saws into wood

Product Type
Stud & Joist Drill
Voltage
60 V
Cordless or Corded
Cordless
Power Source
Battery
Motor Type
Brushless

  • (1) 60V MAX* 7/16-Inch (11mm) Quick-Change Stud and Joist Drill
  • (1) Side handle

  • 3 Year Limited Warranty, 1 Year Free Service, 90 Days Satisfaction Guaranteed

We take extensive measures to ensure all our products are made to the very highest standards and meet all relevant industry regulations.

Customer Support

  • Prop 65 Generic Warning: Yes

Downloads and manuals

N832825_DCD471.pdf
PDF
NA305261_DCD471_T2__NA.pdf
PDF
