DCD740C1
20V MAX* 3/8 in. Right-Angle Drill/Driver Kit
DCD740C1

20V MAX* 3/8 in. Right-Angle Drill/Driver Kit

  • Dual speed ranges (0-650/0-2000) rpm for increased user flexibility providing a wide range of applications
  • Compact front to back length (4.0") allowing users to fit into hard to reach spaces
  • Multi-grip trigger provides comfort and convenience, allowing the user to get into tighter spaces while still having access to the trigger
View more features

Product Overview

Access tight spaces with the compact 20V MAX* 3/8 in. Right-Angle Drill/Driver. Featuring a multi-grip trigger and dual-speed range, this tool provides versatility for a wide range of applications.

Additional Features

  • 3/8" ratcheting chuck with Deep Hex Pocket allows 2" (50 mm) hex bit to be fully inserted for getting into tight spaces

Applications

  • Battery chemistry: XR Li-Ion\nVoltage: 18 V\nBattery Capacity: 1.5 Ah\nMax Torque (Hard): 33 Nm\nMax Torque (Soft): 11 Nm\nPower Output: 360 Watt\nNo Load Speed: 0-650/2000 rpm\nChuck Capacity: 1.0-10 mm\nMax. Drilling Capacity [Wood]: 28 mm\nMax. Drilling Capacity [Metal]: 10 mm\nWeight: 1.75 kg\nLength: 325 mm\nHeight: 102 mm\nWidth: 67 mm\nUncertainty K 1 (Vibration)\n76 dB(A)\nSound Power\n3 dB(A)

Includes

  • (1) 20V MAX 1.5Ah Compact Li-ion Battery
  • (1) Charger
  • (1) Kitbox
  • (1) Belt hook
  • (1) DCD740 3/8 in. Right Angle Drill/Driver

Specifications

Battery Capacity
1.5 Ah
Battery Chemistry
XR Li-ion
Battery Type
LI-ION
Chuck Capacity
1.0 - 10 mm
Max Torque
33 Nm
Max. Drilling Capacity (Metal)
10 mm
No Load Speed (RPM)
0-550/2000
Power Output
360 W
Product Height
325 mm
Product Length
325 mm
Product Weight
1.75 Kg
Product Width
67 mm
Uncertainty K1 (Vibration)
1.5 m/s2
Voltage
18 V

Support

Warranty

  • 3 Year Limited Warranty, 1 Year Free Service, 90 Days Satisfaction Guaranteed

We’re confident of the quality of our products, and we’ll repair, without charge, any defects due to faulty materials or workmanship within the specified warranty.

Learn More

Service

We take extensive measures to ensure all our products are made to the very highest standards and meet all relevant industry regulations.

Support Manual

Disclaimer(s)

  • * Maximum initial battery voltage (measured without a workload) is 20 volts. Nominal voltage is 18.
