20V MAX* XR® Brushless Cordless Compact Router
- Dual LEDs help illuminate the work surface
- Variable-speed dial allows the user to match speed of of the router to the application
- Depth adjustment ring allows for fast and easy height adjustments
Product Overview
Additional Features
- Soft start motor with full-time electronic feedback allows the motor to maintain speed during cuts
- Electronic brake slows the motor down faster after the unit is shut off
Applications
- Cutting edge profiles into various woods
- Flush trimming
- Cutting outdoor hinges
- Dado/slot Cutting
- Cutting dovetails
Includes
- (1) Router Motor
- (1) Fixed Base
- (1) Instruction Manual
- (1) Wrench
Specifications
Battery Type
|
12V MAX*
|
Battery Voltage
|
12 V
|
Brake
|
Yes
|
Brushless
|
Yes
|
Diameter
|
6.35 mm
|
Led light
|
Yes
|
Product Height
|
5 4/5 in
|
Product Height
|
14.6 cm
|
Product Length
|
21.3 cm
|
Product Length
|
8 2/5 in
|
Product Weight
|
1.5 Kg
|
Product Weight
|
4.1 lbs
|
Product Width
|
5 4/5 in
|
Product Width
|
14.8 cm
|
RPM
|
16,000 - 25.500
|
Speed
|
16,000 - 25.500 rpm
|
Variable Speed
|
Yes
|
Related products
Support
Warranty
- 3 Year Limited Warranty, 1 Year Free Service, 90 Days Satisfaction Guaranteed
We’re confident of the quality of our products, and we’ll repair, without charge, any defects due to faulty materials or workmanship within the specified warranty.
Service
We take extensive measures to ensure all our products are made to the very highest standards and meet all relevant industry regulations.
Support Manual
Disclaimer(s)
- * Maximum initial battery voltage (measured without a workload) is 20 volts. Nominal voltage is 18.
